Komatsu D85PX-15 Floor Frame Wiring Harness
Floor Frame Wiring Harness for Komatsu D85PX-15, OEM Quality Replacement Part #154-06-71171
Fitment
Fits the Komatsu D85PX-15. This is the only section ECS currently lists for this machine, so confirm the part number on your old harness against 154-06-71171 before ordering.
Part number reference for the 154-06-71171
This harness is one part sold under one number. Suppliers and parts books write it differently — you may see it as 154-06-71171, 1540671171. They are all the same part; the number on the tag of your old harness is what settles the order.
If the tag shows a different number entirely, do not order by eye — send us a photo of it on WhatsApp and we will match it against the catalogue before anything ships.
Where this harness sits on the Komatsu D85PX-15
It runs along the frame between the front and rear of the machine, clipped to the structure and passing articulation or steering joints.
What it connects
- Front structure to rear structure — the electrical link across the middle of the machine.
- Frame-mounted components to the cab and engine — the circuits that do not run through the main loom.
What a failing Komatsu D85PX-15 harness looks like
| What the operator reports | Why the harness fits that symptom |
|---|---|
| Functions lost when the machine articulates or steers | A run that is being pulled apart at a joint. |
| Faults after rough ground | Clip missing, loom rubbing the frame. |
| Corrosion at the frame connectors | Water trapped in a low point of the loom. |
These are circuit-level symptoms, not a diagnosis. The same behaviour can come from a sensor, an ECM input or a mechanical fault — the checks below are how you tell them apart.
How to confirm it is the harness before you buy
- Compare the part number on the old harness. The number is printed on a tag or moulded into the main connector body. If it does not match, stop — stop here and send us a photo, because two sections of the same machine are not interchangeable.
- Resistance test the suspect run. Disconnect both ends and measure end to end. A reading that is far above the others in the same loom means broken strands; a reading to ground means chafing.
- Wiggle test under load. Back-probe the circuit with the machine running and flex the loom by hand along its length, especially at clips and at the cab or boom entry. If the meter or the fault jumps, you have found the run.
Same type of harness on other machines
Product Description
High-quality floor frame wiring harness designed for Komatsu D85PX-15. This is a complete replacement harness that matches OEM specifications (Part #154-06-71171). All connectors and wiring are tested before shipping. Direct fit installation, no modification required. Made with durable copper wires and heat-resistant insulation for long service life in heavy-duty applications. Factory direct pricing with quality guarantee.
Why Choose ECS System Parts?
- Factory Direct: we build the loom — no middlemen
- In Stock Ready to Ship: most orders leave within 24 hours
- OEM Quality: made to the original drawing, connector for connector
- 1 Year Warranty: full coverage against defects
- Worldwide Shipping: DHL, FedEx, UPS, EMS
- Expert Support: WhatsApp +86-13714733803 — send us a photo of your old harness and we will confirm the section
Technical Specifications
| OEM Part Number | 154-06-71171 |
|---|---|
| Compatible Model | Komatsu D85PX-15 |
| Harness Type | Floor Frame Wiring Harness |
| Warranty | 12 Months |
Shipping Information
- DHL / FedEx / UPS / EMS worldwide
- Ships within 24 hours
- 3-7 days express, 7-15 days standard
- Tracking number provided
Return Policy
- 30-day return window
- Must be unused, original packaging
- Contact via WhatsApp for RMA authorization
